3ZW85
◎ Pump Number: 20210531
◎ Pump Type: 3ZW85
◎ Pressure (bar): 154bar
◎ Flow (L/min): 235.3L/min
◎ Motor Power (KW): 90KW
◎ Medium: Mineral Oil
◎ Medium Temperature ℃: 40～120°C
◎ Valve Accessory Configuration: 1.Safety Valve A22Y-250RL DN25
2.Pressure Relief Valve HY-JF2-00 3.Accumulator NXQ1-L2/20 4.Accumulator NXQ1-L2.5/20
3ZW85
◎ Pump Number: 20201143
◎ Pump Type: 3ZW85
◎ Pressure (bar): 120bar
◎ Flow (L/min): 33.4L/min
◎ Motor Power (KW): 30KW
◎ Medium: Aluminum Silicate Slurry
◎ Medium Temperature ℃: 60°C
◎ Valve Accessory Configuration: 1.Safety Valve HY-A5-00
2.Pressure Relief Valve Ball Valve DN25 16MPa
3ZW85
◎ Pump Number: 20200590
◎ Pump Type: 3ZW85
◎ Pressure (bar): 110bar
◎ Flow (L/min): 353L/min
◎ Motor Power (KW): 90KW
◎ Medium: Deoxygenated Water
◎ Medium Temperature ℃: 104°C
◎ Valve Accessory Configuration: 1.Safety Valve A22Y-160P DN32
2.Pressure Relief Valve HY-JF2-00
3ZW85
◎ Pump Number: 20200566
◎ Pump Type: 3ZW85
◎ Pressure (bar): 320bar
◎ Flow (L/min): 200L/min
◎ Motor Power (KW): 132KW
◎ Medium: Water
◎ Medium Temperature ℃: 80°C
◎ Valve Accessory Configuration: 1.Overflow Valve HY-Y38K-00
2.Safety Valve A22Y-400C DN15
